Product name:Aluminum light rail series

 Press the thumbnail on the right to zoom in

Aluminum light rail series

 Press the thumbnail on the right to zoom in

Product operation-related audio and video

More

Product specifications

1. 2-piece aluminum combined rail 80kg
2. One-piece aluminum rail 200kg
~~~~Must be configured according to span~~~~~

Product Size

types Load(KG) Longest dimension of stringer The longest dimension of the beam Remarks
FA80 80 Unlimited 6M Combined aluminum rail
FA200 200 Unlimited 6M One-piece aluminum rail

Product description

More

1. Aluminum light rail of special lightweight design, aesthetic appearance, corrosion resistance, resistance to heavy load, lightweight, noise free in use, free of jam and iron chip drop or oil drop.
2. This rail is ideal for various types of places, such as automobile assembly plants, clean room, food and chemical plants, medical institutions in various production lines...etc.
3. The design of this product is all based on bolt-type combination, without the need of welding. When the factory or production line needs expansion in the future, it can be easily extended to add more longitudinal beams, and when the factory is relocated or the production line is changed in the future, it can be disassembled and reinstalled to the suitable position with simple hand tools.

Remarks

It can be made into the following types:
1.Monorail effort-saving hanging girder
2.Pillarjib arm
3.Wall-mountedjib arm
4.Double longitudinal beam single crossbeam effort-saving hanging girder
5.Double longitudinal beam double crossbeam effort-saving hanging girder
6.Track-changing effort-saving hanging girder
~~~~ Installation is easy. Material is available for self-installation.~~~
