Product name:Electric crane
Press the thumbnail on the right to zoom in
Press the thumbnail on the right to zoom in
Product specifications
SpTwo-speed host specifications: Voltage: Three-phase voltage, 220V, 60HZ.
Product Size
| Model (Single chain) | Load Capacity |
Speed M/MIN |
Motor output KW |
Model (double chain) | Load Capacity |
Speed M/MIN |
Motor output KW |
| GM2 125.06 | 125KG | 1.5/6 | 0.09/0.35 | GM2 160.03 | 125KG | 0.8/3 | 0.09/0.35 |
| GM2 125.08 | 125KG | 2/8 | 0.09/0.35 | GM2 160.04 | 125KG | 1/4 | 0.09/0.35 |
| GM2 125.10 | 125KG | 2.5/10 | 0.09/0.35 | GM2 160.05 | 125KG | 1.3/5 | 0.09/0.35 |
| GM2 125.12 | 125KG | 3/12 | 0.09/0.35 | GM2 160.06 | 125KG | 1.5/6 | 0.09/0.35 |
| GM2 125.14 | 125KG | 4/16 | 0.09/0.35 | GM2 160.08 | 125KG | 2/8 | 0.09/0.35 |
| GM2 160.06 | 160KG | 1.5/6 | 0.09/0.35 | GM2 160.12 | 160KG |
3/12 |
0.09/0.35 |
| GM2 160.08 | 160KG | 2/8 | 0.09/0.35 | GM2 250.03 | 250KG | 0.8/3 | 0.09/0.35 |
| GM2 160.10 | 160KG | 2.5/10 | 0.09/0.35 | GM2 250.04 | 250KG | 1/4 | 0.09/0.35 |
| GM2 160.12 | 160KG | 3/12 | 0.09/0.35 | GM2 250.05 | 250KG | 1.3/5 | 0.09/0.35 |
| GM4 250.06 | 160KG | 1.5/6 | 0.09/0.35 | GM2 250.06 | 250KG | 1.5/6 | 0.09/0.35 |
| GM4 250.08 | 250KG | 2/86 | 0.09/0.35 | GM2 250.08 | 250KG | 2/8 | 0.09/0.35 |
| GM4 250.08 | 250KG | 2/8 | 0.22/0.90 | GM2 500.03 | 500KG | 0.8/3 | 0.09/0.35 |
| GM4 250.10 | 250KG | 2.5/10 | 0.22/0.90 | GM2 500.04 | 500KG | 1/4 | 0.09/0.35 |
| GM4 250.12 | 250KG | 3/12 | 0.22/0.90 | GM2 500.04 | 500KG | 1/4 | 0.22/0.90 |
| GM4 250-16 | 250KG | 4/16 | 0.22/0.90 | GM2 500.05 | 500KG | 1.3/5 | 0.22/0.90 |
| GM4 250.20 | 250KG | 5/20 | 0.22/0.90 | GM2 500.06 | 500KG | 1.5/6 | 0.22/0.90 |
| GM4 500.08 | 500KG | 2/8 | 0.22/0.90 | GM2 500-08 | 500KG | 2/8 | 0.22/0.90 |
| GM4 500.10 | 500KG | 2.5/10 | 0.22/0.90 | GM2 500-10 | 500KG |
2.5/10 |
0.22/0.90 |
Product description
The crane is a German-made two-speed crane with a load capacity of 125KG~1000KG. The crane is designed as an airtight design with good water resistance and no cooling fan, so there is no dust problem. ABUS cranes are used in one out of every three cranes in Germany.
Two-speed host specifications: Voltage: Three-phase voltage, 220V, 60HZ.
Remarks
★Can be used with simple portal rack (load: 250kg)
