Product name:Electric material handler
Press the thumbnail on the right to zoom in
Press the thumbnail on the right to zoom in
Product specifications
More
Safety design：
1. Standard IP41, Optional: IP66 (dustproof and waterproof)
2. Safe feature during load down
3. Over load protection
4. Over charge protection
5. Battery status display
6. Charger status display
7. Main power switch
8. 3 level central control wheel:
9. Build-in 100-240V charger
10. SUS304 for S series device
11. A series aluminum pillar (lightweight aerospace grade aluminum alloy)
Product Size
SUS304 for S series device
| Part No. | S1160 | S1190 | S1220 |
| Height of main axis(mm) | 1600 | 1900 | 2200 |
| Lift height(mm) | 1300 | 1600 | 1900 |
| Lifting speed | 125 mm/sec | ||
| IP protection | IP41 (Optional IP66-flushable) | ||
| Battery | 24V/10AH Lead-acid battery (optional 24V/15AH lithium battery) | ||
| Charging voltage | 100-240VAC，50/60HZ ( lithium battery：115/230VAC，50/60HZ) | ||
| Charging time | 4hours( lithium battery：2hours) | ||
SUS304 for S series device
| Part No. | S2160 | S2190 | S2220 |
| Height of main axis(mm) | 1600 | 1900 | 2200 |
| Lift height(mm) | 1200 | 1500 | 1800 |
| Lifting speed | 125 mm/sec | ||
| IP protection | IP41 (Optional IP66-flushable) | ||
| Battery | 24V/20AH Lead-acid battery (optional 24V/15AH lithium battery) | ||
| Charging voltage | 100-240VAC，50/60HZ ( lithium battery：115/230VAC，50/60HZ) | ||
| Charging time | 4 hours ( lithium battery：2 hours) | ||
SUS304 for S series device
| Part No. | S3160 | S3190 | S3220 |
| Height of main axis(mm) | 1600 | 1900 | 2200 |
| Lift height(mm) | 1200 | 1500 | 1800 |
| Lifting speed | 125 mm/sec | ||
| IP protection | IP41 (Optional IP66-flushable) | ||
| Battery | 24V/30AH lithium battery | ||
| Charging voltage | 115/230VAC，50/60HZ | ||
| Charging time | 2 hours | ||
SUS304 for S series device
| Part No. | S4160 | S4190 | S4220 |
| Height of main axis(mm) | 1600 | 1900 | 2200 |
| Lift height(mm) | 1200 | 1500 | 1800 |
| Lifting speed | 250 mm/sec | ||
| IP protection | IP41 (Optional IP66-flushable) | ||
| Battery | 24V/20AH Lead-acid battery (optional 24V/15AH lithium battery) | ||
| Charging voltage | 100-240VAC，50/60HZ ( lithium battery：115/230VAC，50/60HZ) | ||
| Charging time | 4 hours ( lithium battery：2 hours) | ||
aluminum pillar
| Part No. | A1190 | A1220 | |
| Height of main axis(mm) | 1900 | 2200 | |
| Lift height(mm) | 1600 | 1800 | |
| Lifting speed | 125 mm/sec | ||
| IP protection | IP41 | ||
| Battery | 24V/10AH Lead-acid battery (optional 24V/15AH lithium battery) | ||
| Charging voltage | 100-240VAC，50/60HZ ( lithium battery：115/230VAC，50/60HZ) | ||
| Charging time | 4 hours ( lithium battery：2 hours) | ||
aluminum pillar
| Part No. | A4190 | A4220 | |
| Height of main axis(mm) | 1900 | 2200 | |
| Lift height(mm) | 1500 | 1800 | |
| Lifting speed | 250 mm/sec | ||
| IP protection | IP41 | ||
| Battery | 24V/10AH Lead-acid battery (optional 24V/15AH lithium battery) | ||
| Charging voltage | 100-240VAC，50/60HZ ( lithium battery：115/230VAC，50/60HZ) | ||
| Charging time | 4 hours ( lithium battery：2 hours) | ||
Product description
More
Purpose of Use:
1. Save operation time
2. Avoid over load and mass transportation
3. Shorten working hours, enhance efficiency
4. Decrease occupational injury and avoid staff turnover
5. One shot investment, saving permanent
